Description
Hot Plug Power Supply For EDFA
Products Number:HSPS75A
Parameters
| Input | 90-264V~50-60Hz | |
| 2A | ||
| Output | +12V | +6.25A |
| 75W | ||
1310nm direct modulation with DFB-LD Transmitter Laser Module
Passive FTTH Optical WDM Receiver Triplexer
Power Supply For Amplifer
$32.00
Additional information
| Power Module | HSPS75A |
|---|
Be the first to review “Power Supply For Amplifer”
Related products
-
1310nm 1490nm 1550nm CATV PD PWDM
$29.00 – $2,900.00 Select optionsQuick View -
16 in 1 ISDB-T Modulator
$1,505.00 Select optionsQuick View -
$21.98 – $4,396.00Features
- 1310nm direct modulation with DFB-LD as Transmitter
- Low noise, Low distortion Low threshold current
- Built-in InGaAs/PIN monitor
- High reliability,Long operation life
Applications
- Optical Transmitter of Analog Signal
- Optical Bidi Module and Optical transceivers
- Test Equipment
Absolute Maximum Ratings (Tc=25℃)
Parameter Symbol Ratings Unit Notes Reverse Voltage（LD） Vr(LD) 2 V CW Forward Current（LD） If(LD) 100 mA CW Reverse Voltage（MPD） Vr(PD) 15 V CW Forward Current（MPD） If(PD) 2 mA CW Storage Temperature Tstg -40~ +85 ℃ – Operating Temperature Topr -20~ +70 ℃ Lead Soldering Temperature/Time Ts 260/10 ℃/S – Fiber Yield Strength – 1 kgf – Fiber Bend Radius – 60 mm – Transmitter Optical and Electrical Characteristics (Tc=25℃)
Parameter Symbol Min Type Max Unit Test Condition Threshold Current Ith 3 – 15 mA CW – – 50 mA CW,T=85℃ Operating Voltage Vf – 1.1 1.5 V – Forward Current If 55 – 65 mA CW, Po=10mW Center Wavelength λc 1540 1550 1560 nm CW, Po= Pf Rise/Fall Time(20-80%) Tr/Tf – 0.2 0.5 nS If=Ith, Po=Pf, 50 Ohm Monitor Current Im 100 – 1000 uA CW, If=Ith+20mA Capacitance C – 10 15 PF VRD=5V, f=1MHz Dark Current Id – – 100 nA VRD=5V Spectral Width(-3dB) Δλ – 0.3 0.5 nm CW, If=Ith+20mA Slope Efficiency SE 0.18 – – W/A CW, If=Ith+20mA Tracking Error TE -1.5 – 1.5 dB CW, If=Ith+20mA Bandwidth BW 2 2.5 – GHz Side Mode Suppression Ratio
SMSR 30 – – dB CW, Po=10mW Optical Isolation ISO 30 – – dB — Relative Intensity Noise RIN – – -130 dB/Hz –
